230 Part Number 80-1479-3 7/10
S1000W
All Self-Contained Water-cooled Before Serial Number
110697023
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
CONDENSER WATER CONSUMPTION
OPERATING PRESSURES
Air Temp.
Around Ice
Machine °F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 6.8-7.9 7.4-8.6 8.5-9.8
.75-2.0
80/27 6.9-8.0 7.5-8.7 8.6-9.9
90/32 6.9-8.1 7.6-8.8 8.7-10.1
100/38 7.0-8.1 7.7-8.9 8.9-10.2
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 5.75 - 6.50 lb.
50/10 70/21 90/32
70/21 1000 930 830
80/27 990 920 820
90/32 980 910 810
100/38 970 900 800
Air Temp. Around Ice
Machine 90°F/32°C
Water Temperature °F/°C
1
1 Water regulating valve set to maintain 240 PSIG discharge pressure
50/10 70/21 90/32
Gal/24 hours 710 1500 5100
Air Temp.
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10
235-245 40-24 160-175 75-90
70/21 235-245 40-25 160-175 75-90
80/27 235-250 42-26 170-185 80-95
90/32 240-270 48-28 175-205 85-105
100/38 250-280 52-28 180-210 90-110
110/43 250-285 54-28 185-215 95-115
