Part Number 80-1479-3 7/10 23
Ice Machine Heat of Rejection
Series Ice
Machine
Heat of Rejection
Air
Conditioning*
Peak
S300 3,800 6,000
S320 3,800 6,000
S420/S450 7,000 9,600
S500 7,000 9,600
S600 9,000 13,900
S850 12,000 18,000
S1000 16,000 22,000
S1200 19,000 28,000
S1400 19,000 28,000
S1600 21,000 31,000
S1800 24,000 36,000
Energy Efficient Machines
S300 5,000 6,000
S420/S450 5,900 6,900
S500 6,100 6,900
S850 13,000 16,000
S1000 17,700 21,000
S1200 20,700 24,500
S1400W 25,000 28,000
S1400A/
S1400N
23,500 27,000
S1800 31,000 36,000
S3300 45,000 51,000
*BTU/Hour
Because the heat of rejection varies during the ice making
cycle, the figure shown is an average.
