226 Part Number 80-1479-3 7/10
SY0894N
Half Dice Cube, Remote Condenser Air-Cooled After
Serial Number 110682385
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
-20/-29 to
70/21
8.1-9.4 8.9-10.3 9.8-11.3
0.75-2.0
90/32 9.1-10.5 9.5-11.0 11.1-12.8
100/38 9.7-11.1 10.7-12.3 11.8-13.6
110/43 10.3-11.9 11.3-13.0 12.7-14.5
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 5.75 -6.5 lb
50/10 70/21 90/32
-20/-29 to 70/21 860 795 730
90/32 780 750 655
100/38 740 680 620
110/43 700 645 585
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 200-220 40-21 140-160 70-85
70/21 225-250 50-30 140-160 70-90
80/27 250-265 55-31 140-160 70-95
90/32 260-295 60-32 140-160 70-95
100/38 310-375 65-35 145-170 75-100
110/43 325-390 70-36 145-170 80-100
