220 Part Number 80-1479-3 7/10
SY0854A
Half Dice Cube, Self-Contained Air-Cooled Models After
Serial Number 110683282
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
35/2 to
70/21
7.3-8.5 8.0-9.3 8.9-10.2
0.75-2.0
90/32 9.4-10.8 9.9-11.4 11.2-12.9
100/38 10.8-12.4 11.7-13.5 12.9-14.8
110/43 12.7-14.5 13.7-15.7 14.9-17.0
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
12
1 Based on average ice slab weight of 5.75 -6.5 lb
2 230/50/1 is approximately 12% lower than 230/60/1
50/10 70/21 90/32
35/2 to 70/21 940 870 800
90/32 760 725 650
100/38 675 625 575
110/43 585 545 505
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 200-255 45-25 125-140 70-90
70/21 200-255 45-26 125-140 75-90
80/27 250-275 50-28 130-160 80-100
90/32 315-260 55-30 160-175 90-115
100/38 330-385 75-34 200-225 130-160
110/43 335-400 78-35 200-230 130-160
