Part Number 80-1479-3 7/10 215
S600 SERIES
S600A
All Self-Contained Air-Cooled Models
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10.0 70/21.1 90/32.2
70/21 7.6-9.0 8.4-9.9 9.1-10.7
1-2.5
80/27 7.8-9.2 8.8-10.3 9.3-10.9
90/32 8.6-10.1 9.5-11.2 10.2-11.9
100/38 9.9-11.7 10.9-12.8 11.4-13.4
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 4.12-4.75 lb.
50/10.0 70/21.1 90/32.2
70/21 650 600 560
80/27 640 580 550
90/32 590 540 510
100/38 520 480 460
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 220-255 45-27 140-160 60-80
70/21 220-270 45-28 145-170 70-90
80/27 230-300 50-30 165-185 75-95
90/32 265-345 54-32 180-215 80-105
100/38 300-395 60-35 210-245 85-120
110/43 340-430 65-39 240-280 100-140
