214 Part Number 80-1479-3 7/10
SY0594N
Half Dice Cube, Remote Air-cooled Condenser Models
After Serial Number 110684316
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
-20/-29 to
70/21
10.9-12.6 12.1-14.0 13.3-15.4
0.75-2.0
90/32 11.8-13.7 12.5-14.5 14.3-16.5
100/38 12.2-14.2 13.5-15.6 14.9-17.2
110/43 12.8-14.9 14.1-16.3 15.5-18.0
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 4.38 - 5.0 lb
50/10 70/21 90/32
-20/-29 to 70/21 510 465 425
90/32 475 450 400
100/38 460 420 385
110/43 440 405 370
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 205-220 50-32 100-150 75-100
70/21 240-260 60-32 110-160 75-100
80/27 240-270 60-32 110-160 75-100
90/32 250-270 60-32 120-160 80-100
100/38 300-375 85-35 130-170 80-100
110/43 310-375 90-36 130-170 80-100
