210 Part Number 80-1479-3 7/10
SD0503W
Dice Cube, Self-Contained Water-cooled Models After
Serial Number 110684316
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
CONDENSER WATER CONSUMPTION
OPERATING PRESSURES
Air Temp.
Around Ice
Machine °F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
35/2 to 70/21 10.0-11.6 11.1-12.9 12.8-14.9
0.75-2.0
90/32 10.4-12.1 11.9-13.8 13.3-15.4
100/38 10.6-12.3 12.1-14.0 13.7-15.8
110/43 10.9-12.6 12.2-14.2 14.1-16.3
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 4.38 - 5.0 lb
50/10 70/21 90/32
35/2 to 70/21 550 500 440
90/32 530 470 425
100/38 520 465 415
110/43 510 460 405
Air Temp. Around Ice
Machine 90°F/32.2°C
Water Temperature °F/°C
1
1 Water regulating valve set to maintain 240 PSIG discharge pressure
50/10 70/21 90/32
Gal/100 lbs. of Ice 355 700 3160
Air Temp.
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 220-230 50-33 125-140 75-110
70/21 220-230 60-33 130-150 95-120
80/27 220-240 65-33 130-160 95-120
90/32 230-250 70-33 170-190 95-120
100/38 235-250 75-33 170-190 95-120
110/43 235-250 75-33 170-190 95-120
