Part Number 80-1479-3 7/10 209
S500W
All Self-Contained Water-cooled Models Before Serial
Number 110684316
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
CONDENSER WATER CONSUMPTION
OPERATING PRESSURES
Air Temp.
Around Ice
Machine °F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 9.3-10.9 10.6-12.5 12.0-14.0
1-2.5
80/27 9.7-11.4 10.9-12.8 12.3-14.4
90/32 9.9-11.7 10.9-12.8 12.6-14.8
100/38 10.1-11.9 11.4-13.4 13.0-15.2
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 4.12-4.75 lb.
50/10 70/21 90/32
70/21 550 490 440
80/27 530 480 430
90/32 520 480 420
100/38 510 460 410
Air Temp. Around Ice
Machine 90°F/32.2°C
Water Temperature °F/°C
1
1 Water regulating valve set to maintain 240 PSIG discharge pressure
50/10 70/21 90/32
Gal/100 lbs. of Ice 87 138 458
Air Temp.
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10
235-240 45-30 160-180 80-115
70/21 235-260 45-30 165-195 90-120
80/27 235-265 46-31 165-195 95-120
90/32 235-265 46-32 165-195 95-120
100/38 235-270 48-32 165-200 100-125
110/43 235-270 50-32 165-205 105-125
