208 Part Number 80-1479-3 7/10
SY0504A
Half Dice Cube, Self-Contained Air-cooled After Serial
Number 110684316
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
35/2 to
70/21
9.8-11.4 10.9-12.6 12.1-14.0
0.75-2.0
90/32 12.2-14.2 12.8-14.9 14.7-17.0
100/38 13.9-16.1 15.1-17.4 16.5-19.1
110/43 16.0-18.5 17.3-20.0 18.8-21.7
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
12
1 Based on average ice slab weight of 4.38 - 5.0 lb
2 230/50/1 is approximately 12% lower than 230/60/1
50/10 70/21 90/32
35/2 to 70/21 560 510 465
90/32 560 440 390
100/38 410 380 350
110/43 360 335 310
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
-20/-29 to
50/10
200-255 50-33 120-145 70-100
70/21 205-260 70-35 130-150 80-110
80/27 210-270 70-36 145-165 80-110
90/32 270-325 70-37 165-190 100-120
100/38 300-400 90-38 210-230 130-150
110/43 330-425 100-38 220-240 140-160
