Part Number 80-1479-3 7/10 197
S320 Series
All Self-Contained Water-Cooled Models
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
CONDENSER WATER CONSUMPTION
OPERATING PRESSURES
Air Temp.
Around Ice
Machine
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 12.7-14.4 13.6-15.5 15.2-17.3
1-2.5
80/27 13.1-14.9 14.1-16.0 15.2-17.3
90/32 13.6-15.5 14.6-16.6 15.8-18.0
100/38 14.1-16.0 15.2-17.3 16.5-18.7
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 3.25-3.65 lb.
50/10 70/21 90/32
70/21 330 310 280
80/27 320 300 280
90/32 310 290 270
100/38 300 280 260
Air Temp. Around Ice
Machine 90°F/32°C
Water Temperature °F/°C
1
1 Water regulating valve set to maintain 240 PSIG discharge pressure
50/10 70/21 90/32
Gal/100 lbs. of Ice 90 160 1010
Air Temp.
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10
235-245 60-38 150-185 85-105
70/21 235-245 68-38 150-190 100-120
80/27 235-250 78-39 155-195 110-145
90/32 235-255 80-40 155-200 115-145
100/38 235-260 82-41 155-205 120-150
110/43 235-265 85-42 155-210 120-150
