Part Number 80-1479-3 7/10 195
S300W
All Self-Contained Water-cooled Models After Serial
Number 110704351
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
CONDENSER WATER CONSUMPTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 9.1-10.9 10.0-11.9 11.1-13.2
1-2.5
80/27 9.3-11.1 10.2-12.2 11.3-13.4
90/32 9.5-11.3 10.4-12.4 11.5-13.7
100/38 9.6-11.5 10.6-12.6 11.8-14.0
110/43 9.8-11.7 10.8-12.9 12.1-14.3
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 2.44 - 2.81 lb.
50/10 70/21 90/32
70/21 325 300 275
80/27 320 295 270
90/32 315 290 265
100/38 310 285 260
110/43 305 280 255
Air Temp. Around Ice
Machine 90°F/32°C
Water Temperature °F/°C
1
1 Water regulating valve set to maintain 240 PSIG discharge pressure
50/10 70/21 90/32
Gal/24 hours 250 510 3300
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 220-230 50-24 130-170 75-100
70/21 220-230 60-25 140-180 90-100
80/27 225-245 65-26 140-185 90-125
90/32 230-250 65-27 145-185 90-130
100/38 230-260 70-28 145-190 90-135
110/43 235-260 70-28 150-190 90-140
