194 Part Number 80-1479-3 7/10
S300W
All Self-Contained Water-cooled Models Before Serial
Number 110704351
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
CONDENSER WATER CONSUMPTION
OPERATING PRESSURES
Air Temp. Around
Ice Machine
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 9.8-11.6 10.8-12.7 12.0-14.7
1-2.5
80/27 10.0-11.8 11.0-13.0 12.3-14.4
90/32 10.4-12.2 11.5-13.5 12.6-14.7
100/38 10.6-12.5 11.8-13.8 12.8-15.0
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 2.44-2.81 lb.
50/10 70/21 90/32
70/21 310 285 260
80/27 305 280 255
90/32 295 270 250
100/38 290 265 245
Air Temp. Around Ice
Machine 90°F/32°C
Water Temperature °F/°C
1
1 Water regulating valve set to maintain 240 PSIG discharge pressure
50/10 70/21 90/32
Gal/24 hours 250 485 2100
Air Temp.
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10
235-245 50-24 140-180 75-100
70/21 235-245 60-25 160-190 90-120
80/27 235-265 65-27 160-190 100-130
90/32 235-275 65-27 160-190 100-135
100/38 235-275 65-28 160-190 100-140
110/43 235-275 65-28 170-200 100-140
