188 Part Number 80-1479-3 7/10
S1000 Before 110697023 36 oz. 26 oz. 8.5 lb. 2 lb. 10.5 lb.
S1000 After 110697023 34 oz. 28 oz. 8.5 lb. 2 lb. 10.5 lb.
S1200 42 oz. 34 oz. NA NA NA
S1400 Before
Manufacture Date 0711
44 oz. 30 oz. 11 lb. 2 lb. 13 lb.
S1400 Between
0711 & 0905
Manufacture Date
44 oz. 52 oz. 11 lb. 2 lb. 13 lb.
S1400 After 0905
Manufacture Date
46 oz. 40 oz. 11 lb. 2 lb. 13 lb.
S1600 48 oz. 36 oz. 11.5 lb. 2 lb. 13.5 lb.
S1800 Before 0910
Manufacture Date
52 oz. 48 oz. 12.5 lb. 1 lb. 13.5 lb.
S1800 After 0910
Manufacture Date
52 oz. 40 oz. 12.5 lb. 1 lb. 13.5 lb.
S3300 NA 6 lb. NA NA NA
Model Air Cooled Water Cooled Remote
Additional
Refrigerant for Line
Sets 51’-100’
Maximum
System Charge
