Part Number 80-1479-3 7/10 187
TOTAL SYSTEM REFRIGERANT CHARGE
NOTE: All machines listed use R-404A refrigerant.
Important
This information is for reference only. Refer to t he ice machine serial number
tag to verify the system charge. Serial plate information overrides information
listed on this page.
Model Air Cooled Water Cooled Remote
Additional
Refrigerant for Line
Sets 51’-100’
Maximum
System Charge
S300 18 oz. 11 oz. NA NA NA
S320 20 oz. 15 oz. NA NA NA
S420/S450 21 oz. 14 oz. NA NA NA
S500 Before 110684316 24 oz. 20 oz. 6 lb. 1.5 lb. 7.5 lb.
S500 After 110684316 24 oz. 23 oz. 6 lb. 1.5 lb. 7.5 lb.
S600 32 oz. 28 oz. 6.5 lb. 1.5 lb. 8 lb.
S850 Before 110683282 36 oz. 26 oz. 8.5 lb. 2 lb. 10.5 lb.
S850 After 110683282 34 oz. 26 oz. 8.5 lb. 2 lb. 10.5 lb.
