186 Part Number 80-1479-3 7/10
FILTER-DRIERS
The filter-driers used on Manitowoc ice machines are
manufactured to Manitowoc specifications.
The difference between a Manitowoc drier and an off-
the-shelf drier is in filtration. A Manitowoc drier has
dirt-retaining filtration, with fiberglass filters on both the
inlet and outlet ends. This is very important because
ice machines have a back-flushing action that takes
place during every Harvest cycle.
A Manitowoc filter-drier has high moisture and acid
removal capability.
The size of the filter-drier is important. The refrigerant
charge is critical. Using an improperly sized filter-drier
will cause the ice machine to be improperly charged
with refrigerant.
Listed below is the recommended OEM field
replacement drier:
Model
Drier
Size
End
Connection
Size
S300A S300W S320A S320W
S420A S420W S450A S450W
S500A S500W S600A S600W
S850A S850W S1000A
S1000W
DML-032S 1/4"
S1200A S1200W DML-052S 1/4"
S500N S600N S850N S1000N
S1400A S1400W S1400N
S1600A S1600W S1600N
S1800A S1800W S1800N
DML-053S 3/8"
S3300W DML-084S 1/2"
Important
Driers are covere d as a warran ty p art. The drier
must be replaced any time the system is opened for
repairs.
