Installation Instructions Section 2
2-4
Part No. 80-1375-3
S970 ICE STORAGE BINS
Remote Condenser Dimensions
JC0495/JC0895/JC1095/JC1395
JC1895
!
Warning
All Manitowoc ice machines require the ice storage
system (bin, dispenser, etc.) to incorporate an ice
deflector.
The Q1300, Q1600 and Q1800 series ice machines
require adding Manitowoc Ice Deflector Kit K00139
when installing with non-Manitowoc ice storage
systems.
Prior to using a non-Manitowoc ice storage system
with other Manitowoc ice machines, contact the
manufacturer to assure their ice deflector is
compatible with Manitowoc ice machines.
SV1610 SV1297
SV1301
