General Information Section 1
1-2
Part No. 80-1375-3
Accessories
Contact your Manitowoc distributor for these optional accessories:
BIN CASTER
Replaces standard legs.
STACKING KIT
As your business grows and your ice needs increase,
Manitowoc stack-on capability can double your daily ice
production without using additional floor space.
ICE BAGGER
Maximize profits from bagged ice sales with this
convenient accessory. This sturdy unit rests on the bin
door frame, and adapts for left or right side filling.
ICE DEFLECTOR
GSI200
This accessory releases chlorine dioxide on a controlled
basis to inhibit the growth of bacteria and slime.
ARCTIC PURE™ WATER FILTER SYSTEM
Engineered specifically for Manitowoc ice machines,
This water filter is an efficient, dependable, and
affordable method of inhibiting scale formation, filtering
sediment, and removing chlorine taste and odor.
MANITOWOC CLEANER AND SANITIZER
Manitowoc Ice Machine Cleaner and Sanitizer are
available in convenient 16 oz. (473 ml) and 1 gal (3.78 l)
bottles. These are the only cleaner and sanitizer
approved for use with Manitowoc products.
AUCS
®
AUTOMATIC CLEANING SYSTEM
This accessory reduces equipment cleaning expense.
The AuCS
®
accessory monitors ice making cycles and
initiates cleaning procedures automatically.
DISPENSER
A counter-top dispenser is ideal for cafeterias and many
types of self-service facilities. Manitowoc auto-fill, floor-
standing ice dispensers meet the strict sanitary
requirements of the food service, lodging and health
care industries.
MANITOWOC CLEANER AND SANITIZER
Manitowoc Ice Machine Cleaner and Sanitizer are
available in convenient 16 oz. (473 ml) and 1 gal (3.78 l)
bottles. These are the only cleaner and sanitizer
approved for use with Manitowoc products.
DISPENSER
A counter-top dispenser is ideal for cafeterias and many
types of self-service facilities. Manitowoc auto-fill, floor-
standing ice dispensers meet the strict sanitary
requirements of the food service, lodging and health
care industries.
!
Warning
All Manitowoc ice machines require the ice storage
(bin, dispenser, etc.) to incorporate an ice deflector.
Prior to using a non-Manitowoc ice storage system
with Manitowoc ice machines, contact the
manufacturer to assure their ice deflector is
compatible with Manitowoc ice machines.
Cleaner Part Number Sanitizer Part Number
16 0z. 94-0456-3 16 0z. 94-0565-3
1 Gallon 94-0580-3 1 Gallon 94-0581-3
Cleaner Part Number Sanitizer Part Number
16 0z. 94-0456-3 16 0z. 94-0565-3
1 Gallon 94-0580-3 1 Gallon 94-0581-3
Revised 6/2003
