COOLANT REPLACEMENT
Once the MCX-2S is connected as described on the preceding pages it is ready to
replace the old coolant with new coolant.
Scales for the tank levels are
graduated in quarts and liters
1 Gallon = 4 Quarts.
1. Determine the capacity and type of coolant for the vehicle cooling system. Refer to
the vehicle Owner’s Manual.
2. Make sure the New Coolant Tank (left slot on front) is filled with the correct coolant
and at a level higher than the amount required to fill the coolant system to full
capacity.
3. Check the Waste Tank (right slot on front) to make sure the level is low enough to
accept the full capacity of coolant in the vehicle cooling system.
Continued on next page . . .
