Appendix F - Error Codes
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 96
Appendix F Error Codes
F.1 H Codes
Table 3-89 - "H" Error Codes
Code
Displayed
Description
Comments
H1
Internal SYSCLK error
USIP bad
H2
Internal GPIO error
USIP bad
H3
Internal RNG error
USIP bad
H4
Internal RTC error
USIP or RTC crystal bad
H5
Internal Timer Init failed
USIP bad
H6
Crypto Engine Init failed
USIP bad
H7
Internal SRAM test failed
USIP bad
H8
Crypto Library Init failed
USIP bad or flash programming failed
H9
HAL Library Init failed
USIP bad
H10*
Crypto Library Self test failed
USIP bad or flash programming failed
H11*
Firmware Signature Check error
FW contents tampered with or failed
H15
Keypad Controller Init failed
Cirque controller or SPI system bad
H16
Unable to communicate with MSR or
mismatched key
MSR, SPI, or cable bad
H17
SDRAM, Touch Panel, Flash, K2 power-
up failure
Peripheral or electronic switch bad
H18
iOS Security Chip Failure
I2C bad
H19
AMS 3911 Failure
Communications with AMS chip failed
F.2 S Codes
Table 3-90 - "S" Error Codes
Code
Calculated
Sn where n
= sum of
the
following
Description
Meaning
+1
Master key storage (BPK) erased or bad
Usually occurs after battery reset or
battery power loss
