Appendix D - MagTek Custom EMV Tags
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 88
Tag
Description
Default (HEX)
Forma
t
Length
DFDF05
Reversal Tags
82 9F 36 9F 1E
9F 10 9F 5B 9F
33 9F 35 95 9F
01 5F 24 5A 5F
34 8A 9F 15 9F
16 9F 39 9F 1A
9F 1C 57 9F 02
5F 2A 9A 9F 21
9C
b
var up to
123
DFDF06
Authorization Response Tags
8A 91
b
var up to
123
DFDF07
Certification Validation Table (Not supported)
00
b
1
DFDF10
Threshold Value for Biased Random Selection
00 00 00 00 40 00
N
6
DFDF11
Target Percentage to be used for Random
Selection (0-99 decimal, or 0-63 hex)
32
b
1
DFDF12
Maximum Target Percentage to be used for
Biased Random Selection (0-99 decimal, or 0-
63 hex)
46
b
1
DFDF13
Default CVM for the application
01
N
1
DFDF14
Socket Timeout
00 00 0B B8
b
4
DFDF15
Socket Retries
00 00 00 01
b
4
DFDF16
Issuer Script max size
00 00 00 80
N
4
DFDF17
Batch Data Tags
82 8E 5F 24 5F
25 9F 06 9F 07
9F 0D 9F 0E 9F
0F 9F 10 9F 26
9F 27 9F 36 95
9B 9C 9F 33 9F
34 9F 37 9F 40
FF 0D FF 0E FF
0F 9F 5B
b
var up to
438
DFDF19
Default Terminal Language
65 6E
b
2
DFDF1A
Transaction Status - Part of F1 container for
status. Always present.
*
b
1
DFDF1B
Additional Transaction Information - Part of F1
container for status. May not be present.
*
b
4
DFDF20
Terminal Features
57
b
1
DFDF21
Number of Applications
0A
b
1
