Appendix D - MagTek Custom EMV Tags
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 87
Appendix D MagTek Custom EMV Tags
In addition to the standard EMV tags documented in EMV 4.3, Book 3, Annex A, MagTek provides
additional custom tags with the device, which are listed in Table 3-80. The characters used in the
“Format” column are described in EMV 4.3, Book 4, Section 4.3.
Table 3-80 - MagTek Custom EMV Tags
Tag
Description
Default (HEX)
Forma
t
Length
F0
Container for Status, Batch, Reversal,
Merchant
*
b
var
F1
Status Data (Constructed Data Object)
*
b
var
F2
Batch Data (Constructed Data Object)
*
b
var
F3
Reversal Data (Constructed Data Object)
*
b
var
F4
Encrypted MSR Data (Constructed Data
Object)
*
b
var
F5
Encrypted PIN Data (Constructed Data Object)
*
b
var
F7
Container for Merchant Data
*
b
var
F8
Container for Encrypted Data
*
b
var
F9
Container For Message Authentication (MAC)
*
b
var
FA
Container for Generic Data
*
b
var
FB
Container for BIN table
*
b
var
FC
Container for Encrypted Generic Data
*
b
var
DFDF00
Random number for random online transaction
8D
b
1
DFDF01
Revoked Certificate Lists (Not supported)
A0 00 00 00 03
96 FF FF FF A0
00 00 00 04 96
FF FF FF A0 00
00 00 05 96 FF
FF FF
b
var up to
72
DFDF02
Authorization Request Tags (ARQC)
9F 03 9F 26 82
5A 5F 34 9F 36
9F 1A 95 9F 02
5F 2A 9A 9C 9F
37 9F 10
b
var up to
158
DFDF03
Advice Tags (Not supported)
5A
b
var up to
161
DFDF04
Financial Request Tags (ARPC) (Not
supported)
91 71 72 9F 01 89
8A
b
var up to
433
