Appendix C - Status and Message Table
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 83
Appendix C Status and Message Table
Table 3-79 - Status and Message Codes
Status/Message
Value
Operation Status
0x00 = OK / Done
0x01 = User Cancel
0x02 = Timeout
0x03 = Host Cancel
0x04 = Verify fail
0x05 = Keypad Security
0x06 = Calibration Done
0x07 = Write with duplicate RID and index
0x08 = Write with corrupted Key
0x09 = CA Public Key reached maximum capacity
0x0A = CA Public Key read with invalid RID or Index
ACK Status
(“ACKSTS”)
0x00 = OK / Done
0x80 = System Error
0x81 = System not Idle
0x82 = Data Error
0x83 = Length Error
0x84 = PAN Exists
0x85 = No Key or Key is incorrect
0x86 = System busy
0x87 = System Locked
0x88 = Auth required
0x89 = Bad Auth
0x8A = System not Available
0x8B = Amount Needed
0x90 = Cert non-exist
0x91 = Expired (Cert/CRL)
0x92 = Invalid (Cert/CRL/Message)
0x93 = Revoked (Cert/CRL)
0x94 = CRL non-exist
0x95 = Cert exists
0x96 = Duplicate KSN/Key
Display Message
0x00 = Hands Off
0x01 = Approved
0x02 = Declined
0x03 = Cancelled
0x04 = Thank You
0x05 = PIN Invalid
0x06 = Processing
0x07 = Please Wait
