3 - Command Set
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 74
Tag
Description
Source
Format
Length
(decimal)
9F37
Value to provide variability and uniqueness
to the generation of a cryptogram
Device
b
4
9F40
Additional Terminal Capabilities
Device
b
5
DFDF70
TAC-default (Terminal Action Codes)
Device
n
5
DFDF71
TAC-Offline (Terminal Action Codes)
Device
n
5
DFDF72
TAC-Online (Terminal Action Codes)
Device
n
5
9F5B
Issuer Script Results
Device
b
0-128
The Merchant Data (F7) Container is included in the response to Report 0xAB – Request EMV
Transaction Data (MAC), which is normally used by the host for receipt printing. The tags in the F7
container are not programmable.
Table 3-75 - Big Block Response to Report 0xAB - Merchant Data Container (F7)
Tag
Description
Source
Format
Length
(decimal)
DFDF30
Masked T1 Status
Device
b
1
DFDF31
Masked T1
Device
b
Var
DFDF32
Masked T2 Status
Device
b
1
DFDF33
Masked T2
Device
b
Var
DFDF34
Masked T3 Status
Device
b
1
DFDF35
Masked T3
Device
b
Var
DFDF3E
Signature Capture
Device
b
Var 0-7000
5F25
Application Effective Date
Card
N6
3
5F24
Application Expiration Date
Card
N6
3
89
Authorization Code
Device
b
6
5F2A
Transaction Currency Code
Card
N3
2
9F02
Amount, authorized
Device
N12
6
9F03
Amount, other
Device
N12
6
9F06
AID - terminal
Device
b
Var 5-16
9F12
Application Preferred Name
Card
ans
Var 1-16
9F1C
Terminal ID
Device
An 8
8
9F39
POS Entry Mode
Device
N2
1
9C
Transaction Type
Device
N2
1
DFDF40
Signature Required
Device
b
1
