3 - Command Set
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 73
Table 3-74 - Big Block Response to Report 0xAB - Batch Data Container (F2 [Default Tags Shown])
Tag
Description
Source
Format
Length
(decimal)
82
Application Interchange Profile
Card
b
2
8E
CVM list
Card
b
0-252
5F24
Date after which the Application expires
Card
n
3
5F25
Date from which the Application can be
used
Card
n
3
9F06
Indicates the Application as described in
ISO/IEC 7816-5
Device
b
5-16
9F07
Indicates issuer's specified restrictions on
the geographic usage and services allowed
for the Application
Card
b
2
9F0D
Specifies the issuer's conditions that cause
a transaction to be rejected if it might
have been approved online, but the
terminal is unable to process the
transaction
online
Card
b
5
9F0E
Specifies the issuer's conditions that cause
the denial of a transaction without
attempt to go online
Card
B
5
9F0F
Specifies the issuer's conditions that cause
a transaction to be transmitted online
Card
B
5
9F10
Contains proprietary application data for
transmission to the issuer in an online
Transaction
Card
b
0-32
9F26
Cryptogram returned by the ICC in
response to the GENERATE AC command
Card
b
8
9F27
Indicates the type of cryptogram and the
actions to be performed by the terminal
Card
b
1
9F36
Counter maintained by the application in
the ICC (incrementing the ATC is
managed by the ICC)
Card
b
2
95
TVR
Device
b
5
9B
TSI
Device
b
2
9C
Transaction Type
Device
b
2
9F33
Terminal Capabilities
Device
b
3
9F34
Indicates the results of the last CVM
performed
Device
b
3
