3 - Command Set
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 72
Table 3-73 - Big Block Response to Report 0xAB - Status Data Container (F1)
Tag
Description
Source
Format
Length
(decimal)
DFDF1A
Transaction Status
0x00 = Accept
0x01 = Decline
0x02 = Error
0x10 = Cancelled by Host
0x11 = Confirm Amount No
0x12 = Confirm Amount Timeout
0x13 = Confirm Amount Cancel
0x14 = MSR Select Credit
0x15 = MSR Select Debit
0x16 = MSR Select Credit/Debit timeout
0x17 = MSR Select Credit/Debit cancel
0x18 = Signature Capture Cancelled by
Host
0x19 = Signature Capture Timeout
0x1A = Signature Capture Cancelled by
User
0x1B = PIN entry Cancelled by Host
0x1C = PIN entry timeout
0x1D = PIN entry Cancelled by User
0x1E = Manual Selection Cancelled by Host
0x1F = Manual Selection timeout
0x20 = Manual Selection Cancelled by User
0x21 = Waiting For Card Cancelled by Host
0x22 = Waiting For Card timeout
0x23 = Waiting For Card Cancelled by User
0xFF = Unknown
Device
b
1
DFDF1B
Additional Transaction Information
0x00 = No additional information
0x31 = Application not selected
0x32 = Error transaction in progress
0x33 = Error invalid PSE format
0x34 = Terminal application list is empty
0x35 = Candidate list is empty
0x36 = No transaction
0x37 = No common applications
0x38 = Transaction canceled
0x39 = Aid parse error
0x3A = Code table index not found
0x3B = Error no more record
0x3C = EMV e overflow
[sic.]
Device
b
4
