3 - Command Set
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 61
Tag
Description
Source
Format
Length
9F03
Secondary amount associated with the
transaction representing a cash back amount
Device
n
6
9F26
Cryptogram returned by the ICC in response of
the GENERATE AC command
Card
b
8
82
Application Interchange Profile
Card
b
2
5A
Application PAN
Card
c
0-10
5F34
Application PAN Sequence Number
Card
n
1
9F36
Application Transaction Counter
Card
b
2
9F1A
Terminal Country Code
Device
n
2
95
TVR
Device
b
5
9F02
Authorized amount of the transactions
(excluding adjustments)
Device
n
6
5F2A
Transaction Currency Code
Device
n
2
9A
Local Date transaction was authorized
Device
n
3
9C
Transaction Type
Device
n
1
9F37
Unpredictable Number
Device
b
4
9F10
Issuer Application Data
Card
b
0-32
DFDF53
Fallback Indicator
Device
n
1
F5
Container For Encrypted PIN
Device
b
Var
F4
Container For Encrypted MSR
Device
b
Var
3.5.9 Report 0x2A – Delayed Response ACK
This event is triggered by completion of longer-running commands that need to report status back to the
host. It is an asynchronous version of Report 0x01 – Response ACK.
Table 3-59 - Usage Table for Report 0x2A
Bit
7
6
5
4
3
2
1
0
Byte 0
0x2A
Byte 1
Status of Command (“ACKSTS”)
Byte 2
ID for Command reporting status
Byte 3..n
Reserved
3.5.10 Report 0x2B – Test Response
Reserved.
3.5.11 Report 0x2D –BLE Module Control Data (BLE Only)
This input report event is triggered by completion of Report 0x1D – Set BLE Module Control Data
(BLE Only) after the device returns Report 0x01 – Response ACK and processes the control data.
