3 - Command Set
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 44
Data length error (e.g., the data size is 0 or is larger than the available buffer size) (0x83)
If the command is successful, the bitmap image or key handling/manufacturing command will be stored
in a predefined buffer within the device.
If the Data Type byte is set to one of the types tagged “Secured,” the first 2 bytes of the data packet
should be the expected length of the message after decryption.
Table 3-21 – Usage Table for Report 0x10 (Block 0)
Bit
7
6
5
4
3
2
1
0
Byte 0
0x10
Byte 1
Data Type:
0x06 = Request user selection user-defined message
0x07 = Display message user defined
0x0C = Bitmap image data
0x17 = Firmware file
0xA0 = EMV data in DOL format (MAC)
0xA1 = EMV data in TLV format, Set EMV Tag(s) (MAC)
0xA4 = EMV data in TLV format, Acquirer Response (ARPC)
0xA5 = CA Public Key Data (MAC)
0xA7 = C-APDU (Secured)
Byte 2
0 = Start of new data set (this packet contains the total data length)
Byte 3
Data Length – low byte (legacy)
Byte 4
Data Length – high byte (legacy) , Data length middle low byte
Byte 5
Data Length – middle high byte
Byte 6
Data Length – high byte
Byte 7
Extended Type: 0= <64K(legacy), 1=>64K
Byte 8..63
reserved
Table 3-22 – Usage Table for Report 0x10 (Blocks 1 through n)
Bit
7
6
5
4
3
2
1
0
Byte 0
0x10
Byte 1
Data type:
0x06 = Request User Selection User Defined Message
0x07 = Display Message User Defined
0x0C = Bitmap image data
0x17 = Firmware file
0xA0 = EMV data in DOL format (Secured)
0xA1 = EMV data in TLV format
0xA4 = EMV data in TLV format, Acquirer Response (ARPC)
0xA5 = CA Public Key Data (MAC)
0xA7 = C-APDU (Secured)
Byte 2
Data packet number (1…n)
