3 - Command Set
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 38
Bit
7
6
5
4
3
2
1
0
Byte 7
EMV L2 ICS Configuration (Default = 0x01)
Note: This setting is ignored when EMV Mode is disabled.
EMV L2 ICS Configuration
0000 = No L2 capability
0001 = Configuration 1C
0010 = Configuration 2C
0011..1111 = Reserved
Byte 8
0x00
3.4.11 Report 0x0A – Request MSR Data
This command causes the device to send MSR data to the host; it should be issued after a Report 0x03 –
Request Swipe Card command has successfully completed. If the system is not available, the device
will report an error (0x8A) in ACKSTS of Report 0x01 – Response ACK. Otherwise, the device will
send multiple instances of Report 0x23 – Card Data Report to the host. If no MSR data is available,
the device will send a single Report 0x23 – Card Data Report containing a Data Length of 0.
Table 3-11 - Usage Table for Report 0x0A
Bit
7
6
5
4
3
2
1
0
Byte 0
0x0A
Byte 1
0x00
3.4.12 Report 0x0B – Get Challenge
This command causes the device to send challenge information to the host. The host should first issue the
command in Set mode as follows:
Table 3-12 - Usage Table for Report 0x0B (Set mode)
Bit
7
6
5
4
3
2
1
0
Byte 0
0x0B
Byte 1
Key ID:
0x00 = PIN key
0x01 = MSR key*
0x02 = PIN Cert
0x03 = MSR Cert
0x04 = Device Authentication signed by PIN cert
0x05 = Device Authentication signed by MSR cert
0x06 = Inject Fixed PIN key signed by PIN cert
0x08 = Inject Authentication key signed by PIN cert
0x09 = Inject Authentication key signed by MSR cert
0x0A = Inject Configuration signed by PIN cert
0x0B = Inject Configuration signed by MSR cert
0x20…0x29 = RESERVED
0x63 = Authentication
0xFF = MFG command
*Note: Use MSR Key when getting challenge to inject Acquirer Master Key
