3 - Command Set
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 26
DFDF3C <Encrypted Magneprint Data><len><val>
DFDF3D <Magneprint Status><len><val>
DFDF43 <Magneprint Status Data><len><val>
DFDF50(MSR KSN Data)<len><val> /*sent in the
clear*/
DFDF51(MSR EncryptionType)<len><val>
F5<len>/* container tag for encrypted PIN data
(normally debit card)*/
99(Encrypted PIN DATA)<len><val>
DFDF41(PIN KSN Data)<len><val>
DFDF42(PIN EncryptionType)<len><val>
(Buffer if any to be a multiple of 8 bytes)
CBC-MAC (4 bytes, use MAC variant of MSR DUKPT key)
3.3.2.2 SRED ARQC Request
Begin with a two-byte header in big-endian form (MSB first) that contains the expected length of the
message after decryption, excluding data padding and CBC-MAC. Use container F9 for the MAC
structure, use container F8 within container FA for passing the encrypted ARQC message, and use the
MAC variant of the MSR DUKPT key.
AAAA /* 2-byte MSB message length excluding padding and CBC-MAC */
F9<len> /* container for MAC structure and generic data */
DFDF54(MAC KSN)<len><val>
DFDF55(MAC Encryption Type)<len><val>
DFDF25(IFD Serial Number)<len><val>
FA<len>/* container for generic data */
70<len> /*container for ARQC */
F8<len> /*container tag for encryption */
DFDF59(Encrypted Data
Primitive)<len><Encrypted Data val (Decrypt data to read tags)>
DFDF56(Encrypted Transaction Data
KSN)<len><val>
DFDF57(Encrypted Transaction Data
Encryption Type)<val>
DFDF58(# of bytes of padding in
DFDF59)<len><val>
(Buffer if any to be a multiple of 8 bytes)
CBC-MAC (4 bytes, use MAC variant of MSR DUKPT key)
The Value inside tag DFDF59 is encrypted and contains the following after decryption:
FC<len>/* container for encrypted generic data */
F4<len>/* container tag for encrypted MSR
data */
DFDF36 <EncT1status><len><val>
DFDF37 <EncT1data><len><val>
DFDF38 <EncT2status><len><val>
DFDF39 <EncT2data><len><val>
DFDF3A <EncT3status><len><val>
DFDF3B <EncT3data><len><val>
DFDF3C <Encrypted Magneprint
Data><len><val>
