2 - Connection Types
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 18
Item
Value (Hex)
Report ID (0x2B) - Input
85 2B
RESERVED
Report ID (0x2C) - Input
85 2C
Usage (EMV Cardholder Interaction Status)
09 2C
Report Count (127)
95 7F
Input (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Buf)
82 02 01
Report ID (0x2D) - Input
85 2D
Usage (BLE Module Control Data)
09 2D
Report Count(64)
95 40
Input (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Buf)
82 02 01
Report ID (0x2E) - Input
85 2E
Usage (Clear Text User Data Entry Response Report)
09 2E
Report Count (12)
95 0C
Input (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Buf)
82 02 01
Report ID (0x30 - Get/Set)
85 30
Usage (Set/Get KSN)
09 30
Report Count(1)
95 01
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Buf)
B2 02 01
Report ID (0x31) - Set
85 31
Usage (Set KSN Encrypted Data)
09 31
Report Count(1)
95 01
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Buf)
B2 02 01
Report ID (0x32) - Get/Set
85 32
Usage (Set/Get BIN Table)
09 32
Report Count(1)
95 01
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Buf)
B2 02 01
Report ID (0x58) - Set
85 58
Usage (Key Handling or Manufacturing Command)
09 58
Report Count (2)
95 02
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Buf)
B2 02 01
Report ID (0xA1) - Set
85 A1
Usage (Set or Get EMV Tag(s))
09 A1
Report Count (8)
95 08
