2 - Connection Types
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 13
descriptor byte-by-byte, a full inventory of the report descriptor for these devices is provided in Table
2-1, which also indicates whether each report is a Get type or Set type or both. The reports themselves
are fully documented in the sections that follow.
Table 2-1 - USB HID Report Descriptor
Item
Value (Hex)
Usage Page
06 20 FF
Usage
09 01
Collection
A1 01
Report Size (8)
75 08
Logical Minimum (0)
15 00
Logical Maximum (255)
26 FF 00
Report ID (0x01) - Get
85 01
Usage (Response ACK)
09 01
Report Count (4)
95 04
Feature (Data,Var,Abs,NWrp,Lin,Pref,NNul,Nvol,Buf)
B2 02 01
Report ID (0x02) - Set
85 02
Usage (End Session)
09 02
Report Count (1)
95 01
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Nvol,Buf)
B2 02 01
Report ID (0x03) - Set
85 03
Usage (Request Swipe Card)
09 03
Report Count (3)
95 03
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Nvol,Buf)
B2 02 01
Report ID (0x04) - Set
85 04
Usage (Request PIN Entry)
09 04
Report Count (5)
95 05
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Nvol,Buf)
B2 02 01
Report ID (0x05) - Set
85 05
Usage (Cancel Command)
09 05
Report Count (1)
95 01
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Nvol,Buf)
B2 02 01
Report ID (0x06) - Set
85 06
Usage (Request User Selection)
09 06
Report Count (4)
95 04
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Nvol,Buf)
B2 02 01
