Owner's manual

Section 2. Installation
5
CONNECTORS
Single Track I/O Connector is shown in Table 2-1, and the Dual Track I/O Connector is shown
in Table 2-2.
Table 2-1. I/O Connector for Single Track, 6 Pin
Pin Number Color Signal
Connector for Single Track, 6 Pin 1 Yellow DATA
2 Orange CARD PRESENT
Molex 6 Pin 3 Green STROBE
22-01-2061 4
−
KEY
0.100 inch Contact Spacing 5 Red V
cc
Mates to Molex 22-05-2061 6 Brown GND
Note: V
cc
= 2.7 to 5.5 VDC
Table 2-2. I/O Connector for Dual Track, 8 Pin
Pin Number Color Signal
Connector for Dual Track, 8 Pin 1 Yellow DATA (Tk 2)
2 White CARD PRESENT
3 Green STROBE (Tk 2)
Molex 8 Pin 4
−
KEY
22-01-2081 5 Red V
cc
0.100 inch Contact Spacing 6 Black GND
7 Blue STROBE (Tk 1 or Tk 3)
Mates to Molex 22-05-2081 8 Brown DATA (Tk 1 or Tk 3)
Note: V
cc
= 2.7 to 5.5 VDC
