Operation Manual

Technical Details:
Supply voltage : 230V - 50/60 Hz
Output relay : Max. 16 Amps. / 230V
Temperature range : +5/+40ºC (Option ºF)
Housing : IP20
Built in back box (deep 50mm single switch back box) according to Standard DIN sizes
Delivered incl. built-in sensor and external (floor) sensor
Colour : Polar white (RAL 9010)
Guarantee : 2 years manufacturers guarantee
Approvals : VDE / FI / CE / CCA
Manufacturer : C&F Technics, The Netherlands
More information:
ENER foil magnum LTD
P.O. Box 2004
Aberfeldy
Perthshire
PH15 2YF
Technical Support: 01887 830638 (Mon-Fri, 9 am –5 pm).
Fax: [phone]
Email: [e-mail]
Energy consumption formula:
The read out of energy consumption is as follows;
30 days x 24 hours x %Last 365 days x Installed power = energy consumption in kWh
100
365 days x 24 hours x %Last 365 days x Installed power = energy consumption in kWh
100
Example:
30 days x 24 hours x 20 (% Last 365 days) x 1.7 (kW installed power) = 244 kWh
100
If the energy consumption screen displays N/A, this means there is no available percentage at present
time. Thermostat hasn’t reached the period of measuring yet.
