User Manual

Cipher Gun

Gun Block Disassembly

1. Pull Catalyst Needle and Resin Needle (CPR-2005-01) from their Housings

2. Remove Nozzle Cap (8704-4-1), Nozzle, and Turbulent Mixer

3. Remove the Mix Housing (5104-20-1) by removing the two Cap Screws (F-CS-

1024-09).

4. Take the Catalyst Injector (5104-03-01) out of the Distribution Ring (5104-17-1)

(see Catalyst Injector Disassembly and Assembly for reference)

5. Remove the Mix Housing Seal (5104-12-1) and Distribution Ring (5104-17-1)

from Mix Housing (5104-20-1).

6. Unscrew Catalyst Needle Housing (CPR-2012-01) from Gun Head (CPR-2001-

01)

7. Unscrew Resin Needle Housing (CPR-2004-01) from Gun Head (CPR-2001-01)

8. Remove Flush Valve Assembly (5104-01-01)

9. Remove Catalyst Plug (53110-1)

10. Remove Resin Fitting (MAX-2022) and Catalyst Fitting (MAX-2019).

Flush Valve Disassembly

1. Remove and discard the Flush Valve Split Seal (5104-21-1) from the Flush

Valve Body (5104-24-1)

2. Remove the Flush Elbow Assembly (5104-02-01) from the Flush Valve Neck

(5104-22-1)

3. Remove the Flush Valve Neck (5104-22-1) and the Flush Valve Seal (5104-26-

1) from the Flush Valve Body (5104-24-1). Discard the Flush Valve Seal (5104-

26-1)

4. Remove the Flush Seal Body (5104-23-1) from the Flush Valve Button (5104-

25-1)

5. Remove the Compression Spring (9203-2-3) from the Flush Valve Body (5104-

24-1)

6. Remove and discard the O-Ring (7301-3-007) from the Flush Seal Body (5104-

23-1)

7. Remove and discard O-Ring (7301-13-008)* from the Flush Valve Button (5104-

25-1)

Catalyst Injector Disassembly

(See drawing Injector Assembly (5104-03-01) for reference)

1. Remove Injector Seal (5104-13-1) from Injector Body (5104-15-1)

2. Unscrew Plunger Retainer (5104-14-1) from Injector Plunger (5104-16-1)

3. Remove Compression Spring (9203-2-2) from Injector Plunger (5104-16-1)

4. Remove Injector Plunger (5104-16-1) from Injector Body (5104-15-1)

NOTE

Discard all parts to be replaced by the repair kit. All remaining parts

should be thoroughly cleaned, inspected for damage, and replaced if

necessary.
