User Manual

Cipher Gun
Cipher Gun
Disassembly
Chapter
1
WARNING
Always remove fluid pressures before working on the unit.
WARNING
Be careful not to bend the catalyst and resin needles.
Initial Disassembly . . .
1. Remove Catalyst, Resin and Flush fluid pressure from system before
disassembly.
2. Remove Catalyst, Resin and Flush lines from the Gun Block Assembly
(CPR-2001-01).
3. Remove Screw (00145) from Trigger Stud (54630-1).
4. Remove Trigger Stud from Gun Handle (54350-3) and Trigger (54360-1).
5. Remove Trigger (54360-1) from gun assembly.
6. To remove the Gun Block Assembly (CPR-2001-01) from Gun Handle
(54350-3) remove Cap Screw (F-CS-04C-12) located at the back center,
just above the Gun Block Assembly (CPR-2001-01).
You now have two components, the Gun Block Assembly and Gun Handle Assembly.
Gun Handle Disassembly
1. Remove Spring Retainers (54000-1) and Springs (04039-1).
2. Remove Valve Body Assembly (54440-1) from Handle (54350-3).
3. Remove Spring (04070-1) and Poppet Assembly (MG-2031).
