Installation Guide

Page 40
© 2010 Magnum Energy, Inc.
Appendix A - Specifi cations
Appendix A - Specifi cations and Optional Equipment
A-1 Inverter/Charger Specifi cations
Models
RD2624E RD4024E
Inverter Specifi cations
Input battery voltage range 18 to 31 VDC 18 to 31 VDC
Absolute maximum DC input 35 VDC 35 VDC
AC output voltage accuracy 230 VAC ± 5%
Output frequency and accuracy 50 Hz ± 0.1 Hz
Continuous power output (at 25° C) 2600 VA 4000 VA
1 msec surge current (amps AC) 85 100
100 msec surge current (amps AC) 22 40
5 sec surge power (real watts) 4700 7500
30 sec surge power (real watts) 4100 6750
5 min surge power (real watts) 3350 6000
30 min surge power (real watts) 2700 5500
Maximum continuous input current 173 ADC 267 ADC
Inverter effi ciency (peak) 93% 93%
HBCO/HBCI (High Battery Cut Out/In) ≥31.6 VDC ≥31.6 VDC
LBCO/LBCI (Low Battery Cut Out/In) 18 VDC (adj)/25 VDC 18 VDC (adj)/25 VDC
Series stacking 120/240 VAC NA
Transfer time 30ms 20ms
Search mode (typical) <7 watts <8 Watts
No load (230 VAC output, typical) 22 watts 32 watts
Waveform Modifi ed Sine Wave
Charger Specifi cations
Continuous Output at 25°C 75 ADC 105 ADC
Input Current - Rated Output (AC amps) 11.5 16
Charger Effi ciency 87% 85%
AC Input Frequency Range 40-60 Hz
AC Input Voltage Range 115-268 VAC
Power Factor >0.95
General Features and Capabilities
Transfer relay capability 30 AAC
Five-stage charging capability Bulk, Absorb, Float, Equalize (requires remote), and Battery Saver ™
Battery temperature compensation Yes, 15 ft. Battery Temperature Sensor standard
Internal cooling 0 to 120 cfm variable speed
Overcurrent protection Yes, with two overlapping circuits
Over-temperature protection Yes, on transformer, MOSFETS, and battery
Corrosion protection Yes, conformal coated PCBs, powder coated chassis and top, stainless steel fasteners
Safety listings None
Warranty Two years
Dual branch-rated output breakers NA
Environmental Specifi cations
Operating temperature -20° C to + 60° C (-4° F to 140° F)
Non-operating temperature -40° C to + 70° C (-40° F to 158° F)
Operating humidity 0 to 95% RH non-condensing
Physical Specifi cations
Unit dimensions (h x w x d) 13.75” x 12.65” x 8.0” (34.9 cm x 32.1 cm x 20.3 cm)
Shipping dimensions (h x w x d) 18.5” x 17.5” x 12.5” (47 cm x 44.5 cm x 31.8 cm)
Mounting Shelf (top or bottom up) or wall
Unit weight 42 lb (19.1 kg) 55 lb (25 kg)
Shipping weight 47 lb (21.3 kg) 60 lb (27.2 kg)
Max operating altitude 15,000 ft (4570 m)
Specifi cations @ 25°C - Subject to change without notice.
