Technical information

Enrange MHR Instruction Manual
August 2014
Page 52 of 57
Alarm
Number
Alarm
Text
Cause of alarm Effect of alarm Recovery Action
44
S44. OUT
13 +VB
SHORT
When the output is
supposed to be at -
VBat, a voltage of 2V
or greater was seen
on the output. The
output was shut off to
prevent damage to
the hardware.
Output is shut off and will
not operate until the cause
is fixed and power to the
system is cycled
Determine the cause of the
short, fix the cause, and power
cycle the system
45
S45. OUT
14 +VB
SHORT
When the output is
supposed to be at -
VBat, a voltage of 2V
or greater was seen
on the output. The
output was shut off to
prevent damage to
the hardware.
Output is shut off and will
not operate until the cause
is fixed and power to the
system is cycled
Determine the cause of the
short, fix the cause, and power
cycle the system
46
S46. OUT
15 +VB
SHORT
When the output is
supposed to be at -
VBat, a voltage of 2V
or greater was seen
on the output. The
output was shut off to
prevent damage to
the hardware.
Output is shut off and will
not operate until the cause
is fixed and power to the
system is cycled
Determine the cause of the
short, fix the cause, and power
cycle the system
47
S47. OUT
16 +VB
SHORT
When the output is
supposed to be at -
VBat, a voltage of 2V
or greater was seen
on the output. The
output was shut off to
prevent damage to
the hardware.
Output is shut off and will
not operate until the cause
is fixed and power to the
system is cycled
Determine the cause of the
short, fix the cause, and power
cycle the system
48
S48. OUT
1 -VB
SHORT
When the output is
supposed to be at
+VBat, a voltage of
2V or less was seen
on the output. The
output was shut off to
prevent damage to
the hardware.
Output is shut off and will
not operate until the cause
is fixed and power to the
system is cycled
Determine the cause of the
short, fix the cause, and power
cycle the system
49
S49. OUT
2 -VB
SHORT
When the output is
supposed to be at
+VBat, a voltage of
2V or less was seen
on the output. The
output was shut off to
prevent damage to
the hardware.
Output is shut off and will
not operate until the cause
is fixed and power to the
system is cycled
Determine the cause of the
short, fix the cause, and power
cycle the system
