Enrange MHR Instruction Manual
August 2014
Page 35 of 57
Figure 16: Unit Status
Field Description
Serial number
Every unit has a unique serial number associated with it.
Project ID
Magnetek assigned project ID.
Access Code
Unit access code that the transmitter needs to know in order to communicate
with the receiver. This is typically the same as the serial number, but can be
changed.
RF Channel
The RF channel number the receiver is set to communicate on.
Time and Date
Current Time and Date.
TX ID
ID of the transmitter which is currently controlling this unit.
Hours
Number of cumulative hours the unit has been on.
Temperature
Temperature within the unit’s enclosure.
3.8 SOFTWARE VERSIONS
This section displays the software versions that are active on the MHR.
There are no user selectable options in this menu item.
To exit the software version screen, press the
button to return to the main setup menu
screen.
3.9 SAVE AND EXIT
This saves all changes and exits the Setup Mode. Upon exit, the device will start up with the new
configuration settings.
3.10 EXIT WITHOUT SAVE
If the user does not wish to save any of the configuration changes made there is an Exit Without
Save option. None of the changes will be saved and the device will then start up with the old
configuration settings.
Serial Number
Pro
j
ect ID
Access Code
Channel
Time & Date
Tem
p
(
°C
)
Hours
TX ID
