(NiCad) Systéme Rechargeable (NiCad) Sistema Recargable (NiCad) Owner’s Manual • Guide d’Utilisation • Manual del Propietario Rechargeable System
For Your Safety Please Read WARNING: Always read and understand all of the warnings and safety instructions contained in this manual before attempting to use the Mag-Lite® Rechargeable Flashlight System™ to help avoid potential hazards that could result in bodily injury or property damage. Always keep this manual conveniently available for future reference, as it contains important information that will help effect the safe operation and maintenance of this instrument.
• Never store or transport flammable liquids, gases or explosive materials in the same compartment as the flashlight or any of its accessories, as possible sparking in the equipment could ignite a fire or explosion. • Always secure this flashlight in its charging cradle, when it is not in use. Never place the flashlight on the passenger seat or anyplace else in the car where it can become a projectile during a collision or sudden stop.
Getting Started What this package contains: (see chart for your system, 1-7) Rechargeable System (NiCad) Systéme Rechargeable (NiCad) Sistema Recargable (NiCad) Contents Getting Started. . . . . . . . . . . . . . . . . . . . 4 The Flashlight. . . . . . . . . . . . . . . . . . . . . 5 The Charging Cradle . . . . . . . . . . . . . . . . 6 Installation. . . . . . . . . . . . . . . . . . . . . . . . 8 The Battery . . . . . . . . . . . . . . . . . . . . . . .
Section 1 The Flashlight 1 2 3 4 6 5 1. Face Cap Assembly (lens and reflector) The Face Cap Assembly is removable for replacement of lamp only. The reflector assembly is factory sealed and should not be removed from face cap (Fig. 1). Lens: The high-efficiency tempered glass lens on the Mag-Lite® Rechargeable Flashlight System™ is an integral part of the optical system. It is precision cut, ground and tempered for its application.
Section 2 The Charging Cradle Charging Cradle Clamps Red LED Power Cord Fig. 3 Flashlight in the Charging Cradle ^ If you have received your system with the flashlight mounted in the Charging Cradle (Fig. 3) the first thing to do is to remove the flashlight. Note A: Since the Charging Cradle was designed to hold the flashlight securely you’ll find that before the unit is mounted, considerable pressure is necessary to release the flashlight from the clamps. It is really quite easy: 1.
Section 2 The Charging Cradle The Charging Cradle’s Quick Release Mounting Bracket Charging Cradle Clamp Arms Turning the Charging Cradle upside down, you will see a release pin on the same side as the power cord (Fig. 5). Depressing this pin with the index finger or (closed) ballpoint pen will release the mounting bracket for installation. When locating and mounting the bracket, be sure that the release pin (Fig. 6) faces in the same direction as you want the head of the flashlight to be.
Section 3 Installation A Typical Installation CAUTION: Make sure wires cannot be pinched. If wire is pinched it can cause immediate short and wires will get hot and melt plastic. 1. Locate and mount the mounting bracket (Fig. 10) using appropriate screw and anchors for that location and material. 2. With flashlight out of the Charging Cradle, engage the two prongs of mounting bracket with matching slots at base of the Charging Cradle … roll it forward and over the spring-loaded pin lock (Fig. 11).
Section 4 The Battery Your Battery’s First Charge Is Important! To assure the freshness of your battery and to avoid any operational problems in shipping, it has been packaged in an UNCHARGED state. For optimum operation of your flashlight, it should be charged a full 16 hours … before using for the first time. Battery Installation If the battery was shipped outside of the flashlight: After you have removed the flashlight from the Charging Cradle unscrew the tail cap (Fig.
Section 5 Operation - Getting the most out of Your Mag-Lite® Rechargeable Flashlight System™ Switch Operation The flashlight utilizes a self-cleaning 3-position rotary switch; on, off, and signal (manual, momentary on-off). When the flashlight is off depressing the switch until it clicks on will provide a sustained beam. Depressing fully again will turn it off. The signal feature can be used by partially depressing the switch until the beam comes on and releasing it for off.
Section 6 Changing the Lamp Changing the Lamp The Halogen Lamp For the ultimate in flashlight power as well as practicality, the Mag-Lite® Rechargeable Flashlight System™ features a halogen, tungsten filament, pin-type replaceable lamp (bulb). Though small in size, its specifications are large: 6 volts, 8.4 watts and a rating of 50 hours.* CAUTION: This bulb is pressurized and CAN SHATTER OR EXPLODE, causing PERSONAL INJURY.
Section 7 Troubleshooting If you have questions or need assistance, please call our warranty/repair facility at (800) 283-5562, in the U.S.A. only, or (909) 947-1006 outside the U.S.A. Problem Flashlight: Does not light Battery charged? Switch sticks Works intermittently Poor or no spot BN Recharger/Cradle: LED indicator does not light when flashlight switch is in off position. Cause/Correction 1. Tighten tail cap – make sure unplated area of tail cap and barrel are clean. 2.
Section 8 Warranty Information Limited Lifetime Flashlight System Warranty/ One Year Battery Pack Warranty MAG INSTRUMENT, INC. (“Mag”) warrants to the original owner that this MAG-LITE® RECHARGEABLE FLASHLIGHT SYSTEM™ (the “SYSTEM”) is free from defects in parts and workmanship. As to the flashlight and other components of the SYSTEM, except the rechargeable NiCad battery supplied herewith, this warranty lasts for the life of the original owner.
www.maglite.com CORPORATE OFFICE MAG INSTRUMENT, INC. 1635 South Sacramento Ave. P.O. Box 50600 Ontario, California U.S.A. 91761-1083 Warranty: (800) 283-5562 or (909) 947-1006 fax: (909) 947-5041 e-mail: warranty@magmail.com Sales & Parts: (800) 289-6241 or (909) 947-1006 email: salesdesk@magmail.com ©2004 Mag Instrument, Inc. • Recharges on either AC or DC current. • Limited Lifetime Warranty (warranty and owners manual enclosed). • Individually serial numbered for identification.
