MAGIC-PRO MP-7VIP-A
52
ACPI Function Enabled: Turn on ACPI function.
Disabled (default): Turn off ACPI function.
Power Management This category allows you to select the type (or degree)
of power saving and is directly related to the follow-
ing modes:
Power Management User Define
HDD Power Down Disable
Doze Mode Disable
Suspend Mode Disable
Item Help
Menu Level
CMOS Setup Utility - Copyright (C) 1984-2000 Award Software
Power Management
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
• Press <Enter> on the Power Management item, then there is a list of it
appears for you to choose further setting.
HDD Power Down When enabled and after the set time of system
inactivity, the hard disk drive will be powered down
while all other devices remain active.
Doze Mode When enabled and after the set time of system
inactivity, the CPU clock will run at slower speed while
all other devices still operate at full speed.
Suspend Mode When enabled and after the set time of system
inactivity, all devices except the CPU will be shut off.
