MG5000 MG5050 SP5500 SP6000 SP7000 Always Armed, Never Disarmed User Guide
Warranty For complete warranty information on this product please refer to the Limited Warranty Statement found on the website www.paradox.com/terms. Your use of the Paradox product signifies your acceptance of all warranty terms and conditions. Limitations of Alarm Systems We strongly advise that you review and take into consideration the “Limitations of Alarm Systems” document available on our website at http://paradox.com/Terms/. Warning for Connections to Non-Traditional Telephony (e.g.
Table of Contents User Settings .................................................................. 2 Stay Arming ............................................................. 14 Zone Settings.................................................................. 3 Bypassing a Zone .................................................... 15 User Codes...................................................................... 4 One-Touch Arming...................................................
User Settings For security reasons, write only the user’s name and not their user code.
Zone Settings Write the device type (motion detector, door contact etc.) and location.
User Codes User codes are personal identification numbers for each user that allow you to enter certain programming modes, arm or disarm your system, as well as activate or deactivate PGMs. The system supports the following: • 1 System Master Code • 2 Master Codes • 29 User Codes System Master Code (Default: 123456) The System Master Code can arm or disarm any partition, and can create, modify or delete any user code.
Setting the Time & Date How do I set the time & date? 1 Press the [TBL] key. 2 Enter your [MASTER CODE]. 3 Press the [ ] key. 4 5 6 7 Press [5]. Enter time in the [HH.MM] format. If the HH is equal to 13 or higher, skip to step 7. Select time format. [1] = 24hr; [2] = AM; [3] = PM. Enter the date in the [YYYY/MM/DD] format. You have now set the time & date. Press [CLEAR] to exit. Setting Chime Zones A chime-enabled zone will advise you every time it is opened by causing your keypad to beep.
Trouble Display Your alarm system continuously monitors several trouble conditions that can be reported directly to your monitoring station. When a trouble condition occurs, the [TBL] key will illuminate. Press the [TBL] key, and the keypad will illuminate a number corresponding to the trouble the system is experiencing. We strongly suggest that you inform your monitoring station of the trouble and allow them to service your system.
Keypads Auditory Feedback When you enter information on the keypad, it will guide you with beep tones that communicate confirmation or rejection of your entries. You should be familiar with these two keypad beep tones: Confirmation Beep: When an operation (e.g. arming/disarming) is successfully entered on the keypad or when the system switches to a new status/mode, the keypad produces an intermittent beep tone (“BEEP-BEEP-BEEPBEEP”).
Keypad Backlight The illumination level behind the keys can be modified to suit your needs. How do I modify the backlight? • For K32 and K32RF: Press and hold the [ ] key. Press the [ ] key to set the desired backlight level. Press [CLEAR] or [ENTER] to exit. For K32I: Press and hold the [S] key for 4 seconds. Keys 1, 2, 3, 5 and 6 will flash. Press [CLEAR] to exit the menu without saving the information or press [ENTER] to exit the menu and save the information.
Keypad Overviews K636 Keypad Overview [TBL] Trouble display [ARM] (page 14) [SLEEP] (page 14) [STAY] (page 14) ON = Trouble(s) occurring (page 6) [MEM] Alarm memory display ON = System armed OFF = Zone disarmed ON = Alarm(s) occurred (page 17) [BYP] Bypass programming ON = Zone(s) bypassed (page 17) Flash = Exit Delay Fast Flash = Exit Delay (final 10 sec.
K32I and K32IRF Keypad Overview = Press once + [MASTER CODE] for Quick Menu programming (see Master Quick Menus on page 24) = Press & hold for keypad settings = Press & hold for chime programming (see Setting Chime Zones on page 5) K32I and K32IRF Icon Display and Description K32I Icon Description StayD On = StayD mode enabled K32IRF Icon Description Indicate Partition 1 and 2 EXIT DELAY Flashing = Enter code before Exit Delay ends OFF On = System is disarmed ENTRY DELAY Flashing = Enter cod
K32 and K32RF Keypad Overview Partition 1 Status Partition 2 Status [TBL] Trouble display ON = Trouble(s) occurring (page 6) [MEM] Alarm memory display ON = Alarm(s) occurred (page 17) [BYP] Bypass programming ON = Zone(s) bypassed (page 17) [ARM] (page 14) [SLEEP] (page 14) [STAY] (page 14) Partition 1 Status Zone Display: The keys [1] to [0(10)] correspond to zones 1 to 10 respectively: Key lit = Open or entry delay Key flash = In alarm = Press once + [MASTER CODE] for Quick Menu Programming (see M
Remote Controls Your security system supports three types of remote controls; the REM1, REM2, and REM3. The REM1 is the most basic remote control, with the ability to perform five actions (e.g. arming, disarming, activating a PGM, etc.). The REM2 is more advanced, as it performs up to six different actions, as well as provides visual and auditory feedback (see table below).
To turn off StayD mode: [OFF] + [CODE] + [OFF] Off light on Press the [OFF] key followed by a valid code, then press the [OFF] key again within ten seconds. The StayD light will turn off and the Off light will light up to confirm StayD deactivation. With StayD disabled, the system will function as a standard security system. To Change Arm Mode (see Arming & Disarming on page 14) To change the level of security - Stay to Sleep: [SLEEP] for 2 sec.
Arming & Disarming Take full advantage of your system by familiarizing yourself with all the arming methods. If your system is not partitioned (see Partitioning on page 22), everything is considered as belonging to Partition 1. NOTE: If you cannot arm because a zone is open, the system will enter in Bypass Programming. Enter the two digit zone you wish to bypass and press [ENTER], or press [ENTER] to bypass all open zones. Regular Arming This method will arm all the zones in the selected partition.
Bypassing a Zone Bypassing a zone allows you to ignore (deactivate) specified zones the next time the system is armed. For example, you may wish to bypass certain zones when workers are renovating part of your home. Once the system is disarmed, the bypass entries are erased. When zones are bypassed, the [BYP] key will illuminate. Zone bypassing can also be activated by using One-Touch Bypass Programming (see page 15).
Figure 1: Arming / Disarming ARM To Sleep Arm: [SLEEP] + Code No Code SLEEP To Disarm: [OFF] + Code No Code To Stay Arm: [STAY] + Code To Disarm: [OFF] + Code No Code STAY To Disarm: [OFF] + Code No Code OFF Auto-Arming Timed Auto Arming The alarm system can automatically arm itself at a specified time every day. As with Regular arming (see Regular Arming on page 14), the system will bypass any open zones. How do I program the Auto-Arm Timer? 1 Press the [ ] key. 2 Enter [MASTER CODE].
Alarms Alarm Display If an alarm has occurred on a zone, the respective zone key will flash, the [MEM] key will light up, and the zones will be stored in memory. These respective keys will continue to flash until disarming even if the zones are restored. To exit this mode and switch to live display mode before disarming, press the [CLEAR] key. When the system is disarmed, the zone keys will turn off, while the [MEM] key remains lit.
your mouth covered. Never return to a burning building for any reason; it may cost you your life. Finally, having at least one working smoke alarm dramatically increases your chances of surviving a fire. And remember to practice a home escape plan frequently with your family. Providing a Fire Warning System Household fires are especially dangerous at night. Fires produce smoke and deadly gases that can overcome occupants while they sleep.
5 Enter the telephone number and press [ENTER]. 6 Select the which group of events will send a text message to the phone number set in step 5 (see Event Call options below). 7 Press [ENTER]. 8 Select which partition(s) is assigned to this telephone number by pressing [1], [2], or both. 9 To save, press [ENTER]. Event Call Options Option [1] [2] [3] [4] Events that send a text message Any alarm (e.g. fire, burglary etc.) Arming and disarming Any trouble (e.g. battery loss) Any trouble restore (e.g.
Partition It is possible to arm or disarm specific partitions. The partitions must be prefaced by the letter A, and separated by commas for individual partitions. It is also possible to affect a series of partitions by writing TO between the start and end partitions of that series. The list of partitions must be followed by a period. Examples:C1234.ARM.A1. C1234.ARM.A1TO2. Phone Number This informs the system of which phone number must be notified by SMS to confirm the status change. Example:C1234.ARM.
VDMP3 Instructions Diagram Magellan / Spectra SP 21
Advanced System Features Programmable Outputs (PGMs) Your system may include one or more PGMs. When a specific event or condition occurs in the system, The PGM can be used to reset smoke detectors, activate light switches in your home or office, open/close garage doors and much more. If programmed by your installer, you can press and hold keys [1] & [2], [2] & [3], [4] & [5], [5] & [6], [7] & [8], or [8] & [9] for each respective PGM.
Panic Alarms Audible N Off [4] & [6] Aux.
Quick Programming Master Quick Menus User Step 1 Action [ ] + [MASTER CODE] 2 3 4 5 [USER NUMBER] [CODE] [CONFIRM CODE] [ENTER] 6 [1] and/or [2] + [ENTER] Details The [ ] key will flash. LED/key on = programmed user. [PARTITION MASTER CODE] may also be used. 2 digits: 01 to 32. Enter a 4 or 6-digit code. Re-enter 4 or 6-digit code. Press [ENTER]. Goes to the next available user, or if partitioned, go to step 6. Assign the user to one or both partitions and press [ENTER].
Assigning a REM3 Hand-Held 2-Way Remote Keypad to the Panel Step 1 Action [ ] + [MASTER CODE] 2 3 4 5 6 [USER NUMBER] [CODE] [CONFIRM CODE] [LEARN REMOTE] [1] and/or [2] + [ENTER] Details The [ ] key will flash. LED/Key on = programmed user [PARTITION MASTER CODE] may also be used. 2 digits: 01 to 32 Enter 4- or 6-digit code. Re-enter 4- or 6-digit code. Press and hold the Information key ([i]) on the designated remote. Assign the user to one or both partitions and press [ENTER].
Index A Access Code Length ..................................................... 4 Adding a User ................................................................ 4 Advanced StayD .......................................................... 13 Advanced System Features ........................................ 22 Alarm Display .............................................................. 17 Alarms ......................................................................... 17 Arming ...............................
Regular ........................................................................ 14 Regular Arming ............................................................ 14 REM3 ..................................................................... 12, 25 Remote Control Feedback ........................................... 12 S Sample Text Messages ............................................... 19 Sending Text Messages to Arm/Disarm ...................... 19 Settings ..................................................
We hope this product performs to your complete satisfaction. Should you have any questions or comments, please visit us at www.paradox.com. PARADOX.
