SECTION 5 SPECIFICATIONS
169000 30 Revision F
SELF-PROPELLED HEADERS (cont’d)
HEADER SIZE 14 FT 16 FT 18 FT
HEADER MODEL A40-D
REEL
Drive Hydraulic Motor 14.2 in
3
(232 cc) /rev
Type
6-Bat
(7 Opt)
Tines Steel: 0.25 in. (6 mm) Dia.
Tine Bar
Bearings
Regreasable Ball
Radius (to tine tip) 22 in. (540 mm)
Maximum
Speed
(rpm)
22T Sprocket
22T Auger
15–85*
19T Auger
19T Sprocket
22T Auger
19T Auger
CONDITIONER
Drive
Hydraulic M44 (44cc) Motor To Enclosed Gearbox
Roll Type
Intermeshing Steel Bars
Roll Diameter
Bars 9.17 in. (233 mm) O.D.
Tube 6.63 in. (168 mm) O.D.
Roll Length
102 in. (2590 mm)
Roll Speed (rpm)
601–810
Unplugging Assist
Reversing Flow To Hydraulic Motors
Forming Shields
Windrower Mounted Side Deflector System For
36 in. (915 mm) to 100 in. (2540 mm) Swath Width
OPERATING SPEED
Recommended Cutting
5 mph (8 km/hr)
* 50–85 rpm for M100, M105, M205.
NOTE: 1. Specifications and design are subject to change without notice or obligation to revise previously sold units.
