SECTION 7 MAINTENANCE AND SERVICING
169000 102 Revision F
7.3.2 Recommended Fluids and Lubricants
Your machine can operate at top efficiency
ONLY if clean lubricants are used.
• Use clean containers to handle
all lubricants.
• Store in an area protected from dust,
moisture, and other contaminants.
LUBRICANT SPEC DESCRIPTION USE CAPACITIES
Grease
SAE
Multi-
Purpose
High Temperature Extreme Pressure
(EP2) Performance With 1% Max
Molybdenum Disulphide (NLGI Grade 2).
Lithium Base.
As Required
Unless Otherwise
Specified
---
High Temperature Extreme Pressure (EP)
Performance With 10% Max Molybdenum
Disulphide (NLGI Grade 2).
Lithium Base.
Driveline
Slip-Joints
Gear Lubricant
SAE
85W-140
API Service Class GL-5
Knife Drive Box 2.3 quarts (2.2 liters)
Conditioner Drive
Gearbox
1.06 quarts (1 liters)
Hydraulic Oil
SAE
15W-40
Compliant With SAE Specs For API Class
SJ And CH-4 Engine Oil.
Steering, Lift, and
Header Drive
Systems
Reservoir
33 gal US (126 liters)
