∆P and T
90
at flow: 100 200 500 1000 Nl/hr
∆P Pressure loss SP30-H../EX2 length 1m < 1 < 1 < 1 < 1 mbar
∆P pressure loss SP30-H1.1-V/EX2
length 1m with new pre-filter V20-2/30
< 1 < 1 1,5 4 mbar
T
90
- time 14 7 < 3 < 2 sec
Pressure difference and T90-time
Temperature controller type HEX5-0.2.08
Ex-marking
II 3 G Ex nA nC nL IIC T5
Ambient temperature 0°C to +50°C
Power supply 230V 50/60Hz max. 800W or 115V 50/60Hz max. 830W
Electrical connection Cable gland, terminal range 6-12mm, terminals max. 4mm
2
Electrical standard EN 61010, EN60519-1
Degree of protection IP65 EN 60529
Temperature status alarm -10°C to T
set
switching capacity 250V 3A AC, 0,25A DC potential free
Excess temperature limiter +5°C to T
set
manual reset
Mounting Wall mounting
Temperature class Operating/sampling temperature °C Limiter °C
T2 (only with thermocouple Fe-CuNi) 280 290
T3 185 190
T4 120 125
T5 85 90
Temperature classes
