Technical Data
Technical specications and illustrations are without
obligation, subject to modications. 03.03/02.08
Gas Sample Probe Version SP2600-H/C/I/BB/F/0,1GF190 SP2600-H/C/I/BB/F/1K190
Part No. 20S3550 20S3540
Integrated backflush via filter element
Protective cover yes
Terminal box IP54 EN60529
Filter housing material Stainless steeel 316 / 316Ti*
Sealing materials FPM*
Probe flange sealing material Novapress
Insitu probe tube/prefilter Optional
Sample pressure max. 0,4-6 bar* abs.
Ambient temperature -20 °C to +60 °C*** /PT100, /Fe-CuNi, /Ni-CrNi** = -20°C to +80°C
Filter chamber volume 280 cm
3
Filter element, porosity 0,1 µm 1µm
Thermostat, Temperature adjustment 0-180°C* /PT100** /Fe-CuNi** /Ni-CrNi**
Ready for operation after 40min
Low temperature alarm contact Change-over contact Contact rating: 250V, 3A~, 0,25A= Alarm point: ∆T 30°C
Sample gas outlet connection 1x 1/4“ NPTi* tube connectors ø 6, 8 or 10 mm**
Backflush/Test gas connection backflush: tube Ø 8mm, span: tube Ø 6mm
Shut off valve connection /I 1/8” NPT i
Pressure range contol air /I 3 - 10 bar
Power supply 230V 50/60 Hz, 800W /115V** = 115V 60Hz, 800W (fuse protection 10A)
Electrical connections Terminals max. 4mm
2
, 2x PG 13,5 cable gland
Electrical equipment standard EN 61010, EN 60519-1
Mounting flange DN65 PN6-B, SS316Ti* >DN or ANSI possible**
Weight 19kg*
* Standard
** Options
*** In case of higher ambient temperatures use option PT100 (Part No. 20S9025) or thermocouple Fe-CuNi respectively Ni-CrNi (Part No. 20S9027 resp. 20S9028) instead of the thermo-
state controller. Then, an additional electronic temperature controller (see data sheet 2-5.1) is necessary.
∆P and T90 at flow of: 100 200 500 1000 1500 Nl/hr
∆P with new filter element S-1K190/0,1GF190 0,007 0,011 0,02 0,035 0,040 bar
T90-time for SP2600-H.. without tube 8 5,5 3 1 <0,5 s
Differential pressure and T
90
-time
Versions and options (extract)
Options (Extract) Data sheet Version Part No.
Execution with power supply 115V/60Hz /115V 20 S 9030
Execution with second outlet for sample gas 1/4" NPTi* /2x* 20 S 9015
Execution with with PT00 sensor instead of the thermostat, without temp. controller /PT100 20 S 9025
Execution with thermoelement FE-CuNi ( type J) instead of thermostat, without temp. controller /Fe-CuN 20 S 9027
Execution with thermoelement Ni-CrNi (type K) instead of thermostat, without temp. controller /Ni-CrNi 20 S 9028
Execution with second PT100 sensor /2-PT100 20 S 9026
Execution with special adapter flange size DN..PN6 or ANSI..150 lbs /DN 20 S 9004
Execution with gas pre-heater GVW1, material SS304 2-1.2.5 /GVW1 20 S 9058
Execution with connection of the gas pre-heater to valve ”BB” and to gas inlet 2-1.2.5 /GVW 20 S 9062
Execution with steam heating, without controller and valves /D 20 S 9033
