Product Specifications

II.DRAWINGOFCURVES
Pout
4.0
3.6
3.2
2.8
2.4
2.0
1.6
1.2
0.8
0.4
0.0
0
Kgcm
8 16 24 32 40
Amp
2.0
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0.0
Eff
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
kRPM
0.10
0.09
0.08
0.07
0.06
0.05
0.04
0.03
0.02
0.01
0.00
kRPM
Pout
Amp
Eff
I.OUTERDIMENSIONS
40mm38mm
15.3
12
III.SPECIFICATIONS
Type:HN-GH34PG
Model:HN-34PGD-2416T-410:1
1.TestingConditions:
Temp:25°Celsius
Humidity:60%
MotorOrientation:Horizontal
2.RatedVoltage:12vdc
3.VoltageOperatingRange:6-12vdc
4.RatedLoadat12vdc:15Kg-cm
Donotexceedratedload.Damagemayoccur!
5.NoLoadSpeedat12vdc:15+/-2RPM
6.SpeedatRatedLoad(15Kg-cm):13+/-2RPM
7.NoLoadCurrentat12vdc:<170mA
8.CurrentatRatedLoad(15Kg-cm):<495mA
9.ShaftEnd-Play:Maximum0.8m/m
10.InsulationResistance:10Mohmat300vdc
11.WithstandVoltage:300vdcfor1Second
12.Thegearmotorisnotintendedforinstantreverse.
Thegearmotormustbestoppedbeforereversing.
13.Thegearmotordoesnotincludeprotectionfrom
waterordustetc.
Datasheetfor:
PGHM-03
12vdc410:114rpm
6mmshaft
www.lynxmotion.com
28mm
35mm
3-M3
6.3
