Operating Guide

72
|
Lutron www.lutron.com
dimmers create ambiance and save energy
•
paddle turns on/off
•
slide up to increase,
down to decrease
•
3 quiet fan speeds for
increased comfort
•
no derating if ganged
•
for use with only one
ceiling paddle fan
•
does not include
locator light
fan controls
quiet 3-speed control
single pole/3-way 1.5 A DVFSQ-F-
DVSCFSQ-F-
quiet 3-speed control
(for use with specific fans such as Hunter
Original Series)
single pole/3-way 2.0 A DVFSQ-F-HO-
DVSCFSQ-F-HO-
Diva
®
|
fan controls
For more information
visit www.lutron.com/diva
•
paddle turns on/off
•
use with any 15 A load
•
general purpose
switching of all sources
and motor loads
•
no derating if ganged
coordinating switches
general purpose switches (120/277 V)
single pole 15 A CA-1PSH-
SC-1PS-
3-way 15 A CA-3PSH-
SC-3PS-
4-way 15 A CA-4PSH-
SC-4PS-
general purpose switch with locator light
(120 V only)
single pole 15 A CA-1PSNL-
SC-1PSNL-
3-way 15 A CA-3PSNL-
SC-3PSNL-
4-way 15 A CA-4PSNL-
SC-4PSNL-
See page 53 for available colors.
To order, add color suffix to model number.
Example: DVFSQ-F-
WH
colors & finishes key
available in gloss finish
available in satin finish
available in all gloss and satin finishes
