User's Manual

RadioRA ® Setup Guide for the Entry Master Control
9
Section 2 - Installation
Installing an Entry Master Control
Step 4 Attach the AC Adapter Step 6 Plug in the AC Adapter
Plug the AC Adapter into a 120VAC, 60Hz wall
receptacle.
Align Entry Master Control
and snap onto wall
bracket.
If the LEDs do not flash when powered,
ensure that the AC adapter is installed
properly and that there is power at the
receptacle. If problem persists, call the
Lutron Technical Support Center at
[phone].
Plug in power
cord.
?
UP
Step 5 Attach to Wall Bracket
