User's Manual

RadioRA ® Setup Guide for the Entry Master Control
2
Notes on this Manual
The procedures to setup a RadioRA® Multi-Function Entry Master Control are contained in this manual. For more
information on programming the remainder of your RadioRA® System, or for advanced features, refer to the
original RadioRA® Setup Guide (P/N 044-001).
Consumer Information
Notice
This Visor Control System, consisting of a Multi-Function Entry Master Control and a Visor Control transmitter, must only be
used to operate visible means of barrier entry such as garage doors and motorized gates. Do not use this Multi-Function
Entry Master Control with any garage door opener that lacks the safety stop and reverse feature as required by federal
safety standards. (This includes any garage door opener model manufactured before April 1, 1982.) A garage door opener
which cannot detect an object, signaling the door to stop and reverse, does not meet current federal safety standards. Using
a garage door opener without these features increases risk of serious injury or death.
Warning
This RadioRA® system must not be used to control equipment, other than lighting, which is not visible from every master or
local control location. It also must not be used to control equipment which could create hazardous situations such as
entrapment if operated accidentally. Examples of equipment which must not be controlled by this RadioRA
® system when
not visible from a Multi-Function Entry Master Control or local control location include (but are not limited to) motorized
gates, garage doors, industrial doors, and microwave ovens, heating pads, etc. It is the installer's responsibility to ensure
that the equipment, other than lighting, being controlled is visible from every master or local control location and that only
suitable equipment is connected to this RadioRA
® system.
FCC Information
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by Lutron Electronics Co. could void the user's authority to operate this equipment.
Important Application Note
The Multi-Function Entry Master Control is a type of Master Control. The RadioRA® System can have a maximum
of 12 Master Controls.
Important Installation Notes
1. Install in accordance with all national and local electrical codes.
2. Do not paint the Multi-Function Entry Master Control.
3. Operate in ambient temperatures between 0°C (32°F) and 40°C (104°F).
4. Do not mount outside. Unit must not get wet.
5. Use only the AC adapter provided by Lutron with your Multi-Function Entry Master Control. Using an AC
adapter not rated at the following specifications could damage the control and possibly overheat the AC
adapter.
• Input: AC 120V 60Hz
• Output: AC 9V/500mA Class 2
6. The range and performance of the RadioRA® System is highly dependent on a variety of complex factors such
as:
• Distance between system components
• Geometry of the home
• Construction of walls separating system components
• Electrical equipment located near system components
