System Overview

Hardware The Luminex 100 Version 1.7 system includes a Luminex 100

Version 1.7 analyzer, the Luminex XYP, and a PC.

The Luminex 100 analyzer includes the following hardware:

• Luminex 100 analyzer

• Sample tube holders (1.5 mL and 1.2 mL)

• Sheath fluid container

• Waste container

• Communications cable to connect analyzer with computer

The Luminex XYP includes the following hardware:

• Luminex XYP instrument

• Power cord

• Communication cable to connect to the Luminex XYP

• Alignment guide

• Luminex XYP sample probe (long probe)

• Reservoir

•Shield

• Luminex XYP heater block

• Probe alignment toolkit

• Allen wrench, 3/32 inch hexagonal

The PC includes the following hardware:

• Computer: a Pentium

microprocessor class PC

• Monitor

• Power cords

• Keyboard

•Mouse
